Nano Comformal Coating EC-6220

EUBO EC-6220 Nano Conformal Coating is a fluorinated compound solution using a fluorine-containing solvent as the medium, providing water- and oil-repellent properties. Due to its very low surface tension, it offers protection against water, moisture, dust, oil, and chemicals, and can be used as a substitute for conventional “three-proof coatings.”

Advantages / Features of EC-6220 Nano Conformal Coating:

1. Rapidly forms a thin, transparent protective film (0.1–1 μm) on the workpiece surface.

2. Extremely low surface tension (11–12 mN/m), easy to apply.

3. Good material compatibility (plastics, metals, glass, and other surfaces).

4. Effective water, oil, stain, dust, and chemical resistance.

5. Fast drying at room temperature, improving work efficiency.

6. Non-toxic, no flash point, high safety.

7. Environmentally friendly: free of chlorine and bromine, does not deplete the ozone layer (ODP = 0), and has low global warming potential (GWP = 0, HGWP = 0.25).

Usage Instructions:

• Apply by brush or immersion coating.

• Clean the surface before application and allow it to dry, then apply as described above.

• Apply in a well-ventilated area; once dried, it has no adverse effects.

Packaging Specifications:

• 6 KG/Carton, 1 KG/Can

Storage Instructions:

• As a volatile product, seal the container immediately after use and store in a cool, dark place.

• Store in a cool, dry place, away from heat sources.

• Avoid contact with oxidizers, strong acids, and alkaline substances.

Precautions:

• This product contains solvents; ensure adequate ventilation during use.

• Wash hands thoroughly before smoking or eating after handling this product.

• May cause irritation to skin or eyes.

• Wear appropriate safety equipment when using this product.

• In case of contact with eyes or skin, rinse immediately with plenty of water and seek medical attention if necessary.

• Wash hands thoroughly after handling.

Limited Warranty Information – Please Read Carefully:
The information provided here is accurate to the best of our knowledge. However, since the conditions and methods of use are beyond our control, this information cannot replace the customer’s own testing to ensure product safety, effectiveness, and suitability for a specific end-use. Any usage recommendations provided must not be construed as infringing on any patents.

Application Range of EC-6220 Nano Conformal Coating:

1. Protective coating for circuit boards and electronic components.

2. Prevents the spread of lubricating oils in precision instruments (such as watches, cameras) or miniature motor bearings.

3. Sealing treatment for precision components.

4. Water- and oil-repellent coating for circuit boards in mobile phones and other mobile communication devices.

5. Protection against corrosion by acidic liquids.

6. Forms a chemically resistant protective layer against salt water, electrolytes, corrosive gases, and similar substances.
